Cisco Catalyst 9200L-24P-4G 24-Port PoE+ Switch, Network Essentials
by
Stackable 24-port PoE+ access switch with four 1G uplinks, 370 W PoE, field-replaceable power and Network Essentials software.
- UL
- CE
- FCC
- CCC
- RoHS
$2,949.99
SKU C9200L-24P-4G-E · 30-day returns
The Cisco Catalyst 9200L-24P-4G-E is an enterprise-class access switch running Cisco IOS XE, aimed at branch offices and departmental closets that want Catalyst 9000 features at an entry price point.
• 24 Gigabit ports with full PoE+; 370 W budget on the default 600 W AC supply, rising to 740 W with a second supply • 4 fixed 1G SFP uplinks • 56 Gbps switching capacity, 41.67 Mpps forwarding • StackWise-80 stacking of up to 8 switches with the optional stack kit • 2 GB DRAM, 4 GB flash, 16,000 MAC entries and 4094 VLAN IDs
The power supply is field-replaceable and a second unit can be added for redundancy. This SKU ships with the Network Essentials software level.
Cisco backs the switch with its Enhanced Limited Lifetime warranty, including next-business-day hardware replacement where available and 90 days of TAC support.
Shipping is charged by the number of items in your order, at the same rates for every destination, and the exact amount is shown at checkout before you pay. Orders ship within 1 business day.
Not happy? Return it within 30 days for a full refund, even if opened.
Specifications
| Part number | C9200L-24P-4G-E |
|---|---|
| Ports | |
| Access ports | 24 x 10/100/1000 RJ-45, full PoE+ |
| Uplinks | 4 x 1G SFP (fixed) |
| Power | |
| PoE budget | 370 W (1 x PWR-C5-600WAC); 740 W with second supply |
| Power supply | Field-replaceable 600 W AC, optional redundant second unit |
| Performance | |
| Switching capacity | 56 Gbps |
| Forwarding rate | 41.67 Mpps |
| Stacking | StackWise-80, 80 Gbps, up to 8 members (kit sold separately) |
| Memory | 2 GB DRAM / 4 GB flash |
| Network | |
| MAC address table | 16,000 entries |
| VLAN IDs | 4094 |
| Physical | |
| Dimensions (H x W x D) | 4.4 x 44.5 x 28.8 cm |
| Weight | 4.71 kg |
| Management | |
| Software | Cisco IOS XE, Network Essentials |
| Warranty | Cisco Enhanced Limited Lifetime hardware warranty (NBD replacement where available, 90 days 8x5 TAC) |
